Cu. Ft (max): 900

Dimensions: 9 1/8″ x 15 1/2″ x 15″

Wall Cutout: 15 5/8″ x 9 3/8″

Outside Louver: 10 1/2″ x 18 1/2″

Maximum Wall Thickness unit can be placed: 6.5″

BTU (max): 3000 BTU/hr

KoolR Consumer‑Friendly Guide

A simple, easy‑to‑read version of your installation, use, and care instructions

Choosing the Right Location

Your KoolR cooling unit works best when installed correctly. Here’s what you need to know:

• Indoor use only. Never install the unit in a fire wall, fire barrier, or fire partition.

• Vent warm air into a large, ventilated interior room. The warm air must flow freely into an adjacent indoor space near the ceiling.

• Do NOT vent into: garages, laundry closets, or any room that traps warm air.

• No ducting. Airflow must be completely unobstructed — the unit moves up to 200 cubic feet of air per minute.

• Keep clear space around the unit. Don’t block airflow on any side.

• Avoid heat sources. Do not install near ovens, radiators, or anywhere below 55°F (13°C).

Temperature Requirements

To keep your wine or pantry items at the right temperature:

• Choose a room where the ambient temperature is no more than 25°F (14°C) above your desired storage temperature.

• The warm‑air venting room must stay between 65°F and 80°F, with humidity below 70%.

• Default temperature is 57°F (14°C).

• You may set the temperature between 53°F and 64°F (12°C–18°C) if conditions allow.

Insulation Requirements

Proper insulation is essential for performance:

• All walls, floors, and ceilings must be insulated to R‑20 with vapor barriers on both sides.

• Floors MUST be insulated. Bare concrete floors radiate heat and humidity.

• Use an insulated door with a good weather seal.

Electrical Requirements

Before installation, make sure you have:

• A dedicated, grounded 15‑amp / 115‑volt outlet on the cool side (Europe: 10‑amp / 220‑volt).

• No extension cords.

• A surge protector to protect electronics.

• An outlet that cannot be turned off by a wall switch.

• Line voltage above 105V.

Always unplug the unit before cleaning or maintenance.

Unpacking Your KoolR

• Use two people — the unit is heavy.

• Remove packaging carefully (avoid sharp tools).

• Vacuum out any leftover packing material.

• Inspect for shipping damage and report major issues to www.wineracking.ca

• Let the unit rest horizontally for 2 hours before powering on.

• Test run for 10 minutes:

  • Display lights up

  • Fans start within 1 minute

  • Compressor starts within the next minute

  • Warm air exits the warm side; cool air exits the cold side

Record your serial number.

Preparing Your Room

Build your wine cellar or pantry with:

• Proper insulation

• A sealed, insulated door

• A dedicated electrical line

Follow the wall‑cutout template for installation.

Installing the KoolR

• Use two people and a safe ladder.

• Attach the decorative grille on the warm side.

• Connect the drain as shown in the template. Improper drain setup can cause water damage.

KoolR is not responsible for any decorative additions that block airflow.

First Startup & Monitoring

For the first 12 hours, monitor the unit closely.

The unit has a safety shutoff at 72°F. During the first 12 hours, the alarm is temporarily ignored so the unit can cool the room properly.

Normal Operating Sounds

Your KoolR may make sounds you’re not used to — this is normal:

• High‑efficiency fans and compressor may run longer

• Pulsing or high‑pitched sounds

• Rattling from refrigerant flow

• Gurgling at the end of cycles

• Water running into the drain pan

• Clicking when starting or stopping

Using the Controls

• Factory preset is 57°F — confirm this at installation.

• Wait 24 hours between temperature adjustments.

• Lower the setting for a colder cellar; raise it for warmer.

• Display shows current temperature unless within 3°F of the set point.

Wine Racks & Stocking

• Never place racks close to or under the cooling unit — airflow must stay open.

• Expect slight temperature differences within the room.

• Liquid temperature stays stable even if air temperature fluctuates.

Lighting

Leaving lights on will warm the room — turn them off when not needed.

Cleaning & Care

Clean monthly:

1. Unplug the unit.

2. Remove the grille.

3. Avoid harsh cleaners or abrasive tools.

4. Vacuum condenser and evaporator coils (may need cleaning every 2 months).

5. Replace grille and plug back in.

Changing the Fuse

Replace only with the same size and amperage. Instructions available at the manufacturer’s website.

Vacation & Moving

If leaving home:

• Remove wine

• Unplug the unit

• Clean it

If moving:

• Remove wine

• Unplug and uninstall

• Use two people — overhead weight can be dangerous

• Clean and pack removable parts

• Reinstall using this guide and the template

Troubleshooting

Unit won’t operate

• Check power cord

• Check household fuse or breaker

• Check unit fuse

Motor runs too much

• Warm weather

• Frequent door opening

• Incorrect control setting

• Door not fully closed

• Dirty coils

Temperature too warm

• Insulation below R‑20

• Frequent door opening

• Blocked grille

• Incorrect control setting

Moisture buildup

• Frequent door opening

• High humidity

• Poor floor insulation

Door won’t close

• Realign door

• Clean gasket

• Apply paraffin wax lightly

Service & Replacement Parts

Check troubleshooting first. For help, visit www.wineracking.ca

Warranty (Consumer Summary)

Your KoolR has a 1‑year limited warranty covering defects in materials and workmanship when used normally in the U.S. or Canada.

Warranty does not cover:

• Misuse, improper installation, or commercial use

• Cosmetic damage after 30 days

• Food or medicine loss

• Pickup/delivery

• Unauthorized modifications

• Missing or altered serial numbers

• Damage from accidents, fire, flood, or acts of God

You may have additional rights depending on your province or state.

Keep your sales slip and record your model and serial number.
